# Landau gauge gluon and ghost propagators at finite temperature from quenched lattice QCD

###### Abstract

The behavior of the Landau gauge gluon and ghost propagators is studied in pure gauge theory at non-zero temperature on the lattice. We concentrate on the momentum range . For the longitudinal as well as for the transverse component of the gluon propagator we extract the continuum limit. We demonstrate the smallness of finite-size and Gribov-copy effects at temperatures close to the deconfinement phase transition at and within the restricted range of momenta. Since the longitudinal component turns out to be most sensitive with respect to the phase transition we propose some combinations of signalling the transition much like “order parameters”.

###### pacs:

11.15.Ha, 12.38.Gc, 12.38.Aw^{†}

^{†}preprint: HU-EP-11/37, ITEP-LAT/2011-07

## I Introduction

It is commonly believed that hadronic matter at high temperature undergoes a phase transition into another phase, traditionally called “quark-gluon plasma”. At present, strong efforts are made at RHIC, BNL and at the LHC, CERN to establish undeniable experimental signatures in the final states of heavy-ion collisions indicating that matter had undergone evolution close to or beyond this transition. The existence of such a transition has been concluded long time ago from Hagedorn’s thermodynamical model Hagedorn (1970) and later has been one of the first crucial forecasts of lattice QCD (LQCD). The latter uses a formulation of non-Abelian gauge theory which is amenable to ab-initio numerical non-perturbative computations. This formulation also opens the way for analytical calculations at strong and weak coupling. LQCD calculations can provide estimates for the transition temperature, the equation of state close to and above and other features and experimental observables. For a recent review see DeTar (2011).

In recent years, another powerful non-perturbative approach has been developed based on Dyson-Schwinger equations (DSE) von Smekal et al. (1998); Hauck et al. (1998); Roberts and Schmidt (2000); Maris and Roberts (2003) and functional renormalization group equations (FRGE) Gies (2002); Pawlowski et al. (2004). The main focus was first to find a field theoretical, model-independent description of quark and gluon confinement in terms of the infrared behavior of gauge-variant Green’s functions, in particular of the Landau or Coulomb gauge gluon and ghost propagators. This should allow to confirm or disprove confinement scenarios as proposed by Gribov and Zwanziger Gribov (1978); Zwanziger (2002, 2004) and Kugo and Ojima Kugo and Ojima (1979); Kugo (1995). Landau gauge gluon and ghost propagators have been intensively studied for zero temperature with DSE and FRGE (see, e.g., Fischer et al. (2009) and citations therein). On the lattice these propagators have been computed by several groups (see Bornyakov et al. (2010); Bogolubsky et al. (2009) for our own recent computations and references to earlier work by other groups).

If these propagators encode confinement, they should also be considerend in LQCD studies at non-vanishing temperature (see Heller et al. (1995, 1998); Cucchieri et al. (2001a, b) and for more recent work Cucchieri et al. (2007); Maas (2010); Fischer et al. (2010); Cucchieri and Mendes (2011)). Complementary to this the temperature dependence has also been studied in the framework of DSE Gruter et al. (2005); Maas et al. (2005); Braun et al. (2010); Fischer (2009).

In the recent past we also have extended our lattice computations of the gluon and ghost propagators at zero temperature to the case of non-zero temperature. First results have been obtained without Bornyakov and Mitrjushkin (2010) and also with dynamical fermion flavors Bornyakov and Mitrjushkin (2011). In this paper we will focus on results for pure SU(3) gauge theory known to have a first order finite temperature phase transition. We concentrate on the continuum limit within a restricted range of momenta. For this range finite-size or Gribov-copy effects turn out to be small. Moreover, a noticeable sensitivity of the longitudinal component of the gluon propagator with respect to the deconfining phase transition is observed. We show that certain ratios of this component may serve as useful indicators (“order parameters”) for this transition, thus complementing the information obtained from the ever popular Polyakov loop.

The paper is organized as follows. In Section II we describe the setup of our lattice Monte Carlo simulation. In Section III we review the basic definitions of the gauge-variant propagators on the lattice, modified to finite temperature. In Section IV we present results for the gluon and ghost propagators for various temperatures. The signal of the phase transition is not as strong as one might have expected. Nevertheless, as it is said above, the longitudinal gluon propagator allows us to define ratios which give a clear signal at the deconfinement phase transition. In Sections V and VI we analyze the finite-volume and Gribov-copy effects, respectively. In Section VII we investigate then scaling properties for varying lattice spacing , keeping the temperature and the volume fixed. This allows us to extrapolate our data to the continuum limit. Finally, in Section VIII, we shall draw our conclusions.

## Ii Setup of the lattice simulations

We have generated pure gauge field configurations on a four-dimensional lattice of size with periodic boundary conditions employing standard Monte Carlo simulations using the Euclidean path integral weight , where denotes the Wilson one-plaquette action

is the bare coupling constant and denotes the link variables. The imaginary-time extent corresponds to the inverse temperature , where is the lattice spacing. For generating the gauge field ensemble we have used the standard hybrid over-relaxation algorithm, with a step of 4 microcanonical over-relaxation sweeps followed by one heatbath step Fabricius and Haan (1984); Kennedy and Pendleton (1985). In both steps a decomposition of SU(3) link variables into SU(2) matrices, as proposed in Cabibbo and Marinari (1982), was applied. combined thermalization sweeps were allowed between the individual measurements of the propagators.

0.65 | 18 | 48 | 6.337 | 0.28 | 0.055 | 150 | 1 |

0.74 | 16 | 48 | 6.337 | 0.28 | 0.055 | 200 | 1 |

0.86 | 14 | 48 | 6.337 | 0.28 | 0.055 | 200 | 1 |

0.99 | 12 | 48 | 6.337 | 0.28 | 0.055 | 200 | 1 |

1.20 | 10 | 48 | 6.337 | 0.28 | 0.055 | 200 | 1 |

1.48 | 8 | 48 | 6.337 | 0.28 | 0.055 | 200 | 1 |

1.98 | 6 | 48 | 6.337 | 0.28 | 0.055 | 200 | 1 |

2.97 | 4 | 48 | 6.337 | 0.28 | 0.055 | 210 | 1 |

0.86 | 8 | 28 | 5.972 | 0.49 | 0.097 | 200 | 27 |

0.86 | 12 | 41 | 6.230 | 0.33 | 0.064 | 200 | 1 |

0.86 | 16 | 55 | 6.440 | 0.24 | 0.048 | 200 | 1 |

1.20 | 6 | 28 | 5.994 | 0.47 | 0.094 | 200 | 27 |

1.20 | 8 | 38 | 6.180 | 0.35 | 0.069 | 200 | 1 |

1.20 | 12 | 58 | 6.490 | 0.23 | 0.045 | 200 | 1 |

0.86 | 14 | 56 | 6.337 | 0.28 | 0.055 | 200 | 1 |

0.86 | 14 | 64 | 6.337 | 0.28 | 0.055 | 200 | 1 |

1.20 | 10 | 56 | 6.337 | 0.28 | 0.055 | 200 | 1 |

1.20 | 10 | 64 | 6.337 | 0.28 | 0.055 | 200 | 1 |

In order to determine the temperature dependence of the gluon and ghost propagators, in a first step we kept the lattice spacing fixed (and, as we shall see, sufficiently small) while varying . As a reference value we have chosen providing (in accordance with Necco and Sommer (2002)). This -value corresponds, for , to a temperature very close to the temperature characteristic for the deconfinement phase transition in a lattice with a linear spatial extent . According to Ref. Boyd et al. (1996) it has been fixed by interpolating with the help of the fit formula

where corresponds to the thermodynamic limit and denotes a fitted coefficient (). guarantees a reasonable aspect ratio over the whole temperature range and permits to reach three-momenta below .

As a second step, we decided to study systematic effects as there are finite-volume effects (cf. Section V), Gribov copy effects (cf. Section VI) and the scaling properties (cf. Section VII) in order to extrapolate to the continuum limit for a couple of momentum values. For the two latter studies we varied while having kept constant the physical spatial volume as well as two representative temperature values ( and , respectively).

A compilation of the lattice sizes and -values together with the number of independent lattice configurations generated for this study can be found in Table 1.

## Iii Gluon and ghost propagators

For determining the gluon and ghost propagators we have to fix the gauge. Under local gauge transformations the link variables transform as

(1) |

In order to satisfy the Landau gauge transversality condition

(2) |

with the lattice gauge potentials

(3) |

it is sufficient to maximize the gauge functional

(4) |

with respect to . What concerns the Gribov non-uniqueness problem for solutions of the gauge condition Eq. (2) we adopt the strategy of finding gauge copies being as close as possible to the global maximum of Parrinello and Jona-Lasinio (1990); Zwanziger (1990) as already practized in Bakeev et al. (2004); Sternbeck et al. (2005); Bogolubsky et al. (2006, 2008); Bornyakov et al. (2010); Bogolubsky et al. (2009). This prescription has been shown to provide correct results for Landau gauge photon and fermion propagators within compact lattice gauge theory Nakamura and Plewnia (1991); Bornyakov et al. (1993); Bogolubsky et al. (1999, 2000). Very efficient for this aim is the simulated annealing (SA) algorithm combined with subsequent overrelaxation (OR) iterations Bali et al. (1995, 1996); Bogolubsky et al. (2007); Bornyakov et al. (2010); Bogolubsky et al. (2009). The SA algorithm generates gauge transformations randomly with a statistical weight . The “temperature” is a technical parameter which is monotonously lowered in the course of SA simulation sweeps (actually, these are heatbath updates). Also, for better performance, a few microcanonical steps are applied after each heatbath step. In fact, we start with and decrease this parameter down to in equal steps after each combined sweep. Finally, in order to satisfy the gauge condition Eq. (2) with a local accuracy of

(5) |

we employ the standard OR procedure. Except for the study of the influence of Gribov copies (cf. Section VI), we carry out only one such attempt per configuration to fix the gauge. As in our previous studies, we call the corresponding (first trial) gauge copy “first copy” (fc).

The gluon propagator is defined in momentum space as

(6) |

where represents the average over configurations, and denotes the Fourier transform of the gauge-fixed gluon field (3) depending on the integer-valued lattice momentum (). The latter is related to the physical momentum (for the Wilson plaquette action) as

(7) |

where characterizes the lattice size.

For non-zero temperature it is convenient to split the propagator into two components, the transverse (“chromomagnetic”) (transverse to the heatbath rest frame) and the longitudinal one (“chromoelectric”), respectively,

(8) |

where plays the rôle of the Matsubara frequency, which will be put to zero lateron. For the Landau gauge, the tensor structures represent projectors transverse and longitudinal relative to the -direction

(9) | |||||

(10) |

For the propagator functions we find

(11) |

and

(12) |

where the number of generators for . The zero-momentum propagator values can be defined as

(13) | |||||

(14) |

Notice that – at least for large enough – the Landau gauge gluon propagator is expected to depend on the -sectors into which the Polyakov loop spatial averages can fall Damm et al. (1998). Therefore, before carrying out the SA gauge fixing procedure we always apply a -flip as described in Section VI but with respect to the 4-th direction. It ensures the phases of the corresponding Polyakov loop averages to fall into the interval .

The Landau gauge ghost propagator and its dressing function are defined as follows.

(15) | |||||

where and . denotes the lattice Faddeev-Popov operator corresponding to the gauge field definition (3) and the related gauge functional (4), i.e.,

(16) |

with

where () are the Hermitian generators of the su(3) Lie algebra satisfying . In order to invert we use the conjugate gradient (CG) algorithm with plane-wave sources with color and position components . Actually, we apply a pre-conditioned CG algorithm to solve the equations , where as pre-conditioning matrix we use the inverse Laplacian with a color-diagonal substructure Sternbeck et al. (2006); Sternbeck (2006).

In order to study hypercubic lattice artifacts, we have analyzed the influence of the choice of momenta on the behavior of the gluon propagator. When comparing on-axis with diagonal momenta (for and in the lower momentum range) we found only small but nonetheless systematic deviations due to the hypercubic lattice geometry. To maximally reduce them the so-called cylinder cut Leinweber et al. (1999)

(17) |

with and has been applied to all our data.

## Iv Results: Gluon and ghost propagators versus temperature

In Fig. 1 we display the multiplicatively renormalized propagators and as functions of the three-momentum () for , obtained with and different , i.e. for temperature values varying from up to . For details we refer to the upper section of Table 1. The renormalization condition is chosen such that take their tree level values at the subtraction point . We choose in order to be close to the perturbative range and still reasonably away from our lattice cutoff ().

One can see from Fig. 1 that the temperature dependence of both and becomes weaker with increasing momentum. This weakening proceeds faster for than for . The ultraviolet regions of and turn out to be “phase-insensitive”. This observation was also reported in Bornyakov and Mitrjushkin (2011). More precisely, while the temperature changes from its minimal value to our maximal one, the change of is less than 5% for GeV, while for this is guaranteed for GeV. For shows a comparatively weak temperature dependence also at small momenta. This changes drastically as soon as . In contrast to that changes monotonously with in the infrared region. This can be seen in more detail from Fig. 2. There we show the temperature dependence of (left panel) as well as of (right panel) for six selected momenta in the range up to .

One can see that at fixed momentum shows strong variations in the
neighbourhood of . It is rising with
below and sharply drops around . This behavior looks most
pronounced for zero momentum and gets progressively weaker at higher
momenta. For the lowest momenta we observe maxima at .
It remains open, whether the maxima are shifted away from the transition
temperature with increasing volume.^{1}^{1}1For gauge theory the maximum of was
recently reported Cucchieri and Mendes (2011) to move away from
the transition with decreasing lattice spacing.

In any case, our data confirms that the infrared part of is strongly sensitive to the temperature phase transition Fischer et al. (2010); Bornyakov and Mitrjushkin (2011). It may serve to construct some kind of order parameters characterizing the onset of the phase transition, as we will propose below. In contrast to that, is ever decreasing and varying smoothly across , showing no visible response to the phase transition at all momenta.

We fit the momentum dependence in the range with a Gribov-Stingl interpolation formula Gribov (1978); Stingl (1996) used in Refs. Cucchieri et al. (2003); Cucchieri and Mendes (2011) and derived lateron in the so-called “Refined Gribov-Zwanziger” approach Dudal et al. (2008, 2011)

(18) |

Expected logarithmic corrections needed for the ultraviolet limit have been
neglected here (for a thorough discussion see Leinweber et al. (1999)).
We put throughout . In a first attempt we have left varying.
We obtained values compatible with except for at the highest
three temperature values inspected. Therefore, in all other cases we have
repeated the fits with fixed and obtained -values
reasonably below . The fit parameters can be found in Table 2.^{2}^{2}2Note that for Eq. (18) is equivalent to
the interpolation formula
Since we expect to see a plateau and even a bend over for
at momenta below our minimal ones the parameter might become nonzero
also at lower temperatures. This would then correspond to a complex
effective mass parameter.

We have tried to form quantities constructed from the gluon propagator which can serve as indicators for the deconfinement transition. First, we plot the ratio

(19) |

as a function of in the left panel of Fig. 3.

We observe that all the curves labelled by the momentum 4-tuples in the legend show approximate plateaux below . Then, passing the phase transition they suddenly fall off with slopes becoming slightly smaller with increasing momentum, but still with visible temperature sensitivity. This means that can be used as an indicator for the deconfinement transition and, moreover, the transition can be traced even at rather high momentum. This was not so clear from the l.h.s. of Fig. 2, where the behavior of at higher momenta looks rather smooth.

From the behavior of , at least in the interval

(20) |

Then, as long as the temperature varies in the given interval, the change of can be described by a momentum independent rescaling. This is a rather nontrivial property from which further conclusions can be drawn. For example, in the interpolation formula (18) above, we should find the mass parameter and the parameter to be (approximately) temperature independent as long as .

From the left panel of Table 2 one can see that this is true for the parameter which varies within error bars. The variation of parameter is up to 30%. This comparatively large variation might be explained by the fact that the propagators were fitted over a wide range of momenta, specifically from to , while the factorization we expect to hold only at low momenta. Indeed, a fit in the range up to GeV which includes also the zero momentum value has shown to become approximately constant. It remains to be seen, whether this behavior in the infrared region survives the continuum and the thermodynamic limites which goes beyond the scope of this paper.

Let us consider another ratio

(21) |

which according to the factorization (20) should be approximately momentum independent. Indeed, this can be seen from the right panel of Fig. 3. Moreover, should resemble qualitatively the temperature dependence of at . Close to , however, falls off reaching very small values at higher temperatures (around ). Therefore, we conclude that both quantities (ceasing to be constant) and (with its strong fall off) signal the finite-temperature transition. It remains to be seen, whether they also map out the (pseudo)critical behavior in unquenched QCD.

Let us note that our volumes are not large enough to study the infrared asymptotic behavior. Moreover, at the lowest momenta we expect systematic deviations due to finite-size effects, lattice artifacts, and Gribov copy effects. This concerns also the parameters and because of their dependence on the value . The systematic effects will be discussed to some extent in Sections V to VII, in order to identify the momentum range, where they play only a negligible rôle.

Summarizing, in agreement with findings in other recent investigations Cucchieri et al. (2007); Maas (2010); Fischer et al. (2010); Bornyakov and Mitrjushkin (2011); Cucchieri and Mendes (2011) we observe the strongest response to the phase transition to occur in the gluonic chromoelectric sector (the longitudinal propagator) rather than in the gluonic chromomagnetic one (the transverse propagator).

We have also computed the ghost propagator according to Eq. (15),
restricting it for simplicity to the diagonal three-momenta and vanishing
Matsubara frequency, with . The data are
again normalized at , such that the ghost dressing function
equals unity at . The result for the latter function is displayed in
Fig. 4. In comparison with the gluon propagator we see the ghost propagator
to change relatively weakly with the temperature.^{3}^{3}3Note the use of a
linear scale at the vertical axis in Fig. 4a in contrast to the logarithmic
one in Fig. 1. This is in agreement with the
observation in Cucchieri et al. (2007).
An increase becomes visible at temperature values for the
lowest momenta studied (see Fig. 4b). The relative insensitivity
with respect to the temperature is the reason why we will not further
consider the ghost propagator in what follows.

## V Finite-volume effects

In order to estimate finite-volume effects we compare the data shown before with data obtained on even larger spatial volumes while keeping fixed the coupling (at ) and two temperature values, (confinement) and (deconfinement), respectively. The linear spatial extent varies from to (see also the middle section in Table 1).

In Figs. 6 and 6 we show the
corresponding plots for and , respectively. In all four cases we
observe the effects to be small for momenta above .^{4}^{4}4
Below the transverse propagator changes by less than 12 %, the longitudinal
one by less than 5 %. Above the transverse propagator varies by less
than 8 % and the longitudinal one by less than 11 %.
For lower momenta, especially at zero momentum, systematic deviations become
more visible. With increasing volume the infrared values of seem
to rise, whereas for the opposite is the case.
This behavior has already been reported for pure gauge theories
in Cucchieri and Mendes (2007); Bornyakov and Mitrjushkin (2010) for and in Bornyakov and Mitrjushkin (2011)
for , respectively.

## Vi Gribov copy effects

In order to study Gribov copy effects we compare “first”, i.e. randomly occuring copies (fc) with “best” copies (bc). The latter were produced as follows.

We searched for copies within all sectors characterized by the phase of the spatial Polyakov loops, i.e. Polyakov loops in one of the three spatial directions. For this purpose the flipping operations Bogolubsky et al. (2006); Bornyakov and Mitrjushkin (2011) were carried out on all link variables () attached and orthogonal to a 3d hyperplane with fixed by multiplying them with . Such global flips are equivalent to non-periodic gauge transformations and do not change the pure gauge action. For the th direction, we stick to the sector with which provides maximal values of the functional (4) at the -values considered in this section Bornyakov and Mitrjushkin (2011). Thus, the flip operations combine for each lattice field configuration the distinct gauge orbits of strictly periodic gauge transformations into one larger gauge orbit.

The number of copies actually considered in each of the 27 sectors depends on the rate of convergence (with increasing number of investigated copies) of the propagator values assigned to the best copy, in particular at zero momentum. From our experience with theory Bornyakov and Mitrjushkin (2011) we expect that the effect of considering gauge copies in different flip-sectors is more important than probing additional gauge copies in each sector. For this reason and to save CPU time we have considered one gauge copy for every -sector; therefore, in total gauge copies for every configuration.

To each copy the simulated annealing algorithm with consecutive overrelaxation was applied in order to fix the gauge. We take the copy with maximal value of the functional (4) as our best realization of the global maximum and denote it as best (“bc”) copy.

The parameters of the SA algorithm in the study of Gribov copies were slightly different from those described above in Section III. 2000 SA combined simulation sweeps with a ratio 11:1 between microcanonical and heat bath sweeps were applied starting with and ending at .

Since this procedure is quite CPU time consuming we restricted this investigation to coarser lattices and with larger lattice spacing, such that both the temperature values and , respectively, as well as the physical 3d volume were approximately reproduced.

In Figs. 8 and 8 we compare bc with fc results for the gluon propagators and , respectively. As one can see, is almost insensitive to the choice of Gribov copies (at least, for the comparatively small values of we consider), as has been already reported in Bornyakov and Mitrjushkin (2010) for the case and in Bornyakov and Mitrjushkin (2011) for the case. On the contrary, the transverse propagator is strongly affected in the infrared region. This observation is independent of the temperature. Moreover, we see that the transverse gluon propagator values in the infrared become lowered for bc compared with fc results. These observations resemble those made already in Bornyakov and Mitrjushkin (2010) and Bornyakov and Mitrjushkin (2011).

The main conclusion of this section is that Gribov copy effects may be neglected for all nonzero momenta in the case of the longitudial propagator (at least, for comparatively small values of ), and for momenta above 800 MeV in the case of the transverse propagator. The momentum range where the last statement is true might depend on the temperature.

## Vii Scaling and continuum limit

In order to check for good scaling properties we have used the same reference values for the temperature below and above as discussed before (i.e., and ). We kept also the spatial volume fixed at . We compare the renormalized propagators at four different values for the lattice spacing (see Table 1). Our results are displayed for the momentum range up to 1.5 GeV in Fig. 10 for and in Fig. 10 for , respectively. Gauge fixing has been carried out as originally described in Section III.

We provide the renormalization factors for

(22) |

in the left panel of Table 3. As expected the -factors of and approximately agree.

From Figs. 10 and 10 we see that the scaling violations happen to be reasonably small for momenta above . This shows that our choice of for was already close to the continuum limit.

In order to study the -dependence at five particular physical momenta we need interpolations of the momentum dependence in between the data points. For the fit within the interval we have used again Eq. (18) with parameter fixed to zero. The values of the fit parameters are displayed in the right hand panels of Table 3. In all cases we find -values per degree of freedom around or below unity.

The propagators, now interpolated to the set of selected momentum values, are shown in Fig. 12 for and in Fig. 12 for , respectively, as functions of the lattice spacing . We show them together with the respective fit curves

(23) |

assuming only lattice artifacts.

The corresponding fit results are collected in Table 4. The respective fit parameters represent the continuum limit values of the propagators at the preselected momenta.

Our lattice propagator data obtained for as discussed in Section IV can now be compared with the values extrapolated to the continuum limit. This is shown in Fig. 13. In more detail, we can compare the continuum extrapolated values at some lower momentum – say at – with those obtained from and interpolated to the same momentum. Then we find deviations being smaller than 4 %. Thus, we are really justified to say that the results obtained for in the given momentum range are already very close to the continuum limit.

The continuum limit extrapolated propagators can be easily interpolated with formula Eq. (18). The results are drawn in Fig. 14.

We conclude that for the higher -values and the momentum range considered in this paper we are close to the continuum limit. Moreover, systematic effects as there are finite-volume and Gribov copy effects seem to be negligible for momenta above .

## Viii Conclusions

We have presented lattice results for the Landau gauge gluon and ghost propagators computed in pure gauge lattice theory at non-zero temperatures.

Overall, our results agree with those published in Fischer et al. (2010) and there are hardly any deviations which are not due to the lattice discretization or the finite volume. However, our aim here was to go a step further and to provide results in the continuum limit for temperatures below and above the deconfinement phase transition, and this with negligible systematic finite-volume and Gribov copy effects. For this to become feasible we had to restrict the analysis to a well-defined momentum range around .

The systematic effects were studied at two temperatures, and , such that we cannot really tell, what happens very close to . Since for our reference value the critical temperature is reached with , there is hope that also in this case we keep close to the continuum limit and the other systematic effects are under control.

Our results and their parametrization can be further used to compare with the outcome of Dyson-Schwinger or functional renormalization group equations for the gluon propagators or employed as reliable input in Dyson-Schwinger studies of the quark propagator. It is well-known that the non-perturbative continuum approaches rely on a truncated tower of equations for the propagators and vertex functions. The way of how it is truncated has a strong influence on the behavior, especially at intermediate momenta. Lattice results from first principles as those presented here can help to tune the truncation correspondingly.

Concentrating on this aim we have been forced to choose the lattice spacing and the linear spatial lattice extent such that we were prevented from going far towards the infrared limit. Therefore, we were not able to clarify the question, what the correct behavior is in the far infrared region. Concerning this region we know, that the Gribov problem is serious and still not completely understood. This is also the reason, why we did not try in this paper to give estimates for the color-electric and -magnetic screening masses.

Our results confirm that, contrary to the transverse gluon propagator and to the ghost propagator , the longitudinal gluon propagator is sensitive to the deconfinement transition. However, despite of the fact that we are faced with a first order phase transition the response to it occurs relatively smooth. We were able to propose two parameters built from which can be employed as indicators (kind of “order parameters”) for the transition itself. One might hope that they will help to shed additional light on the transition region also in full QCD. There, at least for quark flavours within the range of intermediate pion masses a rather smooth crossover is expected (see e.g. DeTar (2011) and references therein, as well as Bornyakov et al. (2011); Burger et al. (2011)). We shall come back to this question in the near future.

## Acknowledgments

We acknowledge useful discussions with F. Burger, C. Fischer, A. Maas, T. Mendes, J. Pawlowski, and L. von Smekal. R. A. gratefully acknowledges financial support by the Yousef Jameel Foundation, A. S. from the European Reintegration Grant (FP7-PEOPLE-2009-RG No.256594), V.K.M. and M.M.-P. by the Heisenberg-Landau program agreed upon between JINR and the German BMBF, V.B. by the Federal Programme Cadres of the Russian Ministry of Science and Education as well as by the grants RFBR 09-02-00338-a and NSh-6260.2010.2. We thank the HLRN Berlin-Hannover and the JINR Computing Center for generous supply with computing time.

## References

- Hagedorn (1970) R. Hagedorn, Nucl.Phys. B24, 93 (1970).
- DeTar (2011) C. DeTar (2011), eprint 1101.0208.
- von Smekal et al. (1998) L. von Smekal, A. Hauck, and R. Alkofer, Ann. Phys. 267, 1 (1998), eprint hep-ph/9707327.
- Hauck et al. (1998) A. Hauck, L. von Smekal, and R. Alkofer, Comput.Phys.Commun. 112, 166 (1998), eprint hep-ph/9804376.
- Roberts and Schmidt (2000) C. D. Roberts and S. M. Schmidt, Prog.Part.Nucl.Phys. 45, S1 (2000), eprint nucl-th/0005064.
- Maris and Roberts (2003) P. Maris and C. D. Roberts, Int.J.Mod.Phys. E12, 297 (2003), eprint nucl-th/0301049.
- Gies (2002) H. Gies, Phys.Rev. D66, 025006 (2002), eprint hep-th/0202207.
- Pawlowski et al. (2004) J. M. Pawlowski, D. F. Litim, S. Nedelko, and L. von Smekal, Phys. Rev. Lett. 93, 152002 (2004), eprint hep-th/0312324.
- Gribov (1978) V. N. Gribov, Nucl. Phys. B139, 1 (1978).
- Zwanziger (2002) D. Zwanziger, Phys. Rev. D65, 094039 (2002), eprint hep-th/0109224.
- Zwanziger (2004) D. Zwanziger, Phys. Rev. D69, 016002 (2004), eprint hep-ph/0303028.
- Kugo and Ojima (1979) T. Kugo and I. Ojima, Prog. Theor. Phys. Suppl. 66, 1 (1979).
- Kugo (1995) T. Kugo (1995), eprint hep-th/9511033.
- Fischer et al. (2009) C. S. Fischer, A. Maas, and J. M. Pawlowski, Annals Phys. 324, 2408 (2009), eprint 0810.1987.
- Bornyakov et al. (2010) V. G. Bornyakov, V. K. Mitrjushkin, and M. Müller-Preussker, Phys. Rev. D81, 054503 (2010), eprint 0912.4475.
- Bogolubsky et al. (2009) I. L. Bogolubsky, E.-M. Ilgenfritz, M. Müller-Preussker, and A. Sternbeck, Phys. Lett. B676, 69 (2009), eprint 0901.0736.
- Heller et al. (1995) U. M. Heller, F. Karsch, and J. Rank, Phys. Lett. B355, 511 (1995), eprint hep-lat/9505016.
- Heller et al. (1998) U. M. Heller, F. Karsch, and J. Rank, Phys. Rev. D57, 1438 (1998), eprint hep-lat/9710033.
- Cucchieri et al. (2001a) A. Cucchieri, F. Karsch, and P. Petreczky, Phys. Lett. B497, 80 (2001a), eprint hep-lat/0004027.
- Cucchieri et al. (2001b) A. Cucchieri, F. Karsch, and P. Petreczky, Phys. Rev. D64, 036001 (2001b), eprint hep-lat/0103009.
- Cucchieri et al. (2007) A. Cucchieri, A. Maas, and T. Mendes, Phys. Rev. D75, 076003 (2007), eprint hep-lat/0702022.
- Maas (2010) A. Maas, Chin. J. Phys. 34, 1328 (2010), eprint 0911.0348.
- Fischer et al. (2010) C. S. Fischer, A. Maas, and J. A. Müller, Eur. Phys. J. C68, 165 (2010), eprint 1003.1960.
- Cucchieri and Mendes (2011) A. Cucchieri and T. Mendes (2011), eprint 1105.0176.
- Gruter et al. (2005) B. Gruter, R. Alkofer, A. Maas, and J. Wambach, Eur.Phys.J. C42, 109 (2005), eprint hep-ph/0408282.
- Maas et al. (2005) A. Maas, J. Wambach, and R. Alkofer, Eur.Phys.J. C42, 93 (2005), eprint hep-ph/0504019.
- Braun et al. (2010) J. Braun, H. Gies, and J. M. Pawlowski, Phys. Lett. B684, 262 (2010), eprint 0708.2413.
- Fischer (2009) C. S. Fischer, Phys.Rev.Lett. 103, 052003 (2009), eprint 0904.2700.
- Bornyakov and Mitrjushkin (2010) V. Bornyakov and V. Mitrjushkin (2010), eprint 1011.4790.
- Bornyakov and Mitrjushkin (2011) V. G. Bornyakov and V. K. Mitrjushkin (2011), eprint 1103.0442.
- Fabricius and Haan (1984) K. Fabricius and O. Haan, Phys.Lett. B143, 459 (1984).
- Kennedy and Pendleton (1985) A. Kennedy and B. Pendleton, Phys.Lett. B156, 393 (1985).
- Cabibbo and Marinari (1982) N. Cabibbo and E. Marinari, Phys. Lett. B119, 387 (1982).
- Necco and Sommer (2002) S. Necco and R. Sommer, Nucl. Phys. B622, 328 (2002), eprint hep-lat/0108008.
- Boyd et al. (1996) G. Boyd, J. Engels, F. Karsch, E. Laermann, C. Legeland, et al., Nucl.Phys. B469, 419 (1996), eprint hep-lat/9602007.
- Parrinello and Jona-Lasinio (1990) C. Parrinello and G. Jona-Lasinio, Phys. Lett. B251, 175 (1990).
- Zwanziger (1990) D. Zwanziger, Nucl. Phys. B345, 461 (1990).
- Bakeev et al. (2004) T. D. Bakeev, E.-M. Ilgenfritz, V. K. Mitrjushkin, and M. Müller-Preussker, Phys. Rev. D69, 074507 (2004), eprint hep-lat/0311041.
- Sternbeck et al. (2005) A. Sternbeck, E.-M. Ilgenfritz, M. Müller-Preussker, and A. Schiller, Phys. Rev. D72, 014507 (2005), eprint hep-lat/0506007.
- Bogolubsky et al. (2006) I. L. Bogolubsky, G. Burgio, V. K. Mitrjushkin, and M. Müller-Preussker, Phys. Rev. D74, 034503 (2006), eprint hep-lat/0511056.
- Bogolubsky et al. (2008) I. L. Bogolubsky, V. G. Bornyakov, G. Burgio, E.-M. Ilgenfritz, V. K. Mitrjushkin, and M. Müller-Preussker, Phys. Rev. D77, 014504 (2008), eprint 0707.3611.
- Nakamura and Plewnia (1991) A. Nakamura and M. Plewnia, Phys. Lett. B255, 274 (1991).
- Bornyakov et al. (1993) V. G. Bornyakov, V. K. Mitrjushkin, M. Müller-Preussker, and F. Pahl, Phys. Lett. B317, 596 (1993), eprint hep-lat/9307010.
- Bogolubsky et al. (1999) I. L. Bogolubsky, V. K. Mitrjushkin, M. Müller-Preussker, and P. Peter, Phys. Lett. B458, 102 (1999), eprint hep-lat/9904001.
- Bogolubsky et al. (2000) I. L. Bogolubsky, V. K. Mitrjushkin, M. Müller-Preussker, P. Peter, and N. V. Zverev, Phys. Lett. B476, 448 (2000), eprint hep-lat/9912017.
- Bali et al. (1995) G. S. Bali, V. Bornyakov, M. Müller-Preussker, and F. Pahl, Nucl. Phys. Proc. Suppl. 42, 852 (1995), eprint hep-lat/9412027.
- Bali et al. (1996) G. S. Bali, V. Bornyakov, M. Müller-Preussker, and K. Schilling, Phys. Rev. D54, 2863 (1996), eprint hep-lat/9603012.
- Bogolubsky et al. (2007) I. L. Bogolubsky, V. G. Bornyakov, G. Burgio, E.-M. Ilgenfritz, V. K. Mitrjushkin, M. Müller-Preussker, and P. Schemel, PoS LAT2007, 318 (2007), eprint 0710.3234.
- Damm et al. (1998) G. Damm, W. Kerler, and V. K. Mitrjushkin, Phys. Lett. B433, 88 (1998), eprint hep-lat/9802028.
- Sternbeck et al. (2006) A. Sternbeck, E.-M. Ilgenfritz, M. Müller-Preussker, A. Schiller, and I. L. Bogolubsky, PoS LAT2006, 076 (2006), eprint hep-lat/0610053.
- Sternbeck (2006) A. Sternbeck, PhD thesis, Humboldt-University Berlin (2006), eprint hep-lat/0609016.
- Leinweber et al. (1999) D. B. Leinweber, J. I. Skullerud, A. G. Williams, and C. Parrinello (UKQCD), Phys. Rev. D60, 094507 (1999), eprint hep-lat/9811027.
- Stingl (1996) M. Stingl, Z.Phys. A353, 423 (1996), eprint hep-th/9502157.
- Cucchieri et al. (2003) A. Cucchieri, T. Mendes, and A. R. Taurines, Phys.Rev. D67, 091502 (2003), eprint hep-lat/0302022.
- Dudal et al. (2008) D. Dudal, J. A. Gracey, S. P. Sorella, N. Vandersickel, and H. Verschelde, Phys. Rev. D78, 065047 (2008), eprint 0806.4348.
- Dudal et al. (2011) D. Dudal, S. Sorella, and N. Vandersickel, Phys.Rev. D84, 065039 (2011), eprint 1105.3371.
- Cucchieri and Mendes (2007) A. Cucchieri and T. Mendes, PoS LAT2007, 297 (2007), eprint 0710.0412.
- Bornyakov et al. (2011) V. Bornyakov, R. Horsley, Y. Nakamura, M. Polikarpov, P. Rakow, et al. (2011), eprint 1102.4461.
- Burger et al. (2011) F. Burger, E.-M. Ilgenfritz, M. Kirchner, M. Lombardo, M. Müller-Preussker, et al. (2011), eprint 1102.4530.
